This is a new product. Please allow 1-2 weeks for shipping.
The factory spring perches on these trucks are short and prone to deforming under heavy loads causing the axle to twist or wrap the leaf springs. The ESP kit fits over the factory perches with a design that is roughly twice the length, helping reduce axle wrap by spreading the load out on the leaf spring while improving durability, with no cutting required.
This kit also replaces the factory ZR2 lift block and includes a U-bolt flip kit, improving ground clearance and providing a stronger, more secure mounting setup.
Want to run bigger tires? These new spring perches also move the rear axle back around 3/8 of an inch to prevent larger tires from rubbing the front edge of the bed, with no body trimming required.
Reuse your factory bump stop or upgrade to the Timbren offroad bumpstop (ABSOSR).
This kit is available in two sizes:
- 0–1" | Offers no lift for ZR2 and 1" of lift for non-ZR2 trucks
- 1–2" | Offers 1" of lift for ZR2 and 2" of lift for non-ZR2 trucks
Key Features
-
-
Longer Spring Perches – Almost 2x factory length to spread out the load on the spring and help reduce axle wrap
-
Replaces Factory Lift Block – Cleaner and stronger setup compared to the OEM ZR2 block
-
Includes U-Bolt Flip Kit – Improved ground clearance
- Moves Rear Axle Rearward 3/8" – Helps improve clearance for larger tires with body trimming required
-
Longer Spring Perches – Almost 2x factory length to spread out the load on the spring and help reduce axle wrap
- Available in 0–1" and 1–2" variations
- Includes U-bolts and flip kit for improved clearance and strength
- Bolt-on installation (welding recommended if factory perches are damaged)
- 1/4" thick steel construction
- Black powder coated finish
- Reuses factory bump stops or Timbren offroad bumpstops
- Welding is not required unless factory spring perches are damaged
- Made in the USA
- Designed for off-road use
- Fits all 2015–2022 Colorado and Canyon trim levels
- You need to check clearances with aftermarket shocks when combining with a rear shock relocation kit
- Installation instructions coming soon
